Harfington Uxcell 5Pcs AC 20A/125V 22A/250V SPDT 3 Terminal 3 Position Boat Rocker Switch Black

Uxcell 5Pcs AC 20A/125V 22A/250V SPDT 3 Terminal 3 Position Boat Rocker Switch Black

ID:
$8.56 Regular price
/
Wholesale Price
35%OFF
Order $5000+
  • 35%OFF
    Order $5000+
  • 25%OFF
    Order $2000+
  • 15%OFF
    Order $800+
  • 10%OFF
    Order $500+
  • 5%OFF
    Order $200+
About this item
  • 【Wide Application】Universal for Electromagnetic furnace, Water dispenser, buses, boats, marine, trailers,kitchen appliance etc.
  • 【DIY As You Like】Black Boat Rocker Switch, 3 terminals ON/OFF/ON switch, , longer life for use.
  • 【Product Basic Parameters】AC 20A/125V 22A/250V Overall Size:32 x 14 x 35mm (L*W*H) Mounting Size:30 x 10mm (L*W)
  • 【Attention】Select the appropriate soldering iron to speed up the soldering. It is recommended to use 20W soldering iron to complete the soldering within 3 seconds. The flux must be in proper amount. When soldering, try to turn the switch pin down.
  • 【Parcel contains】5x Rocker Switch Easy to install and durable.With our strict quality control system, we test each item and ensure in good condition before we ship.
  • In stock, ready to ship
Cart
Cart
About this item
  • 【Wide Application】Universal for Electromagnetic furnace, Water dispenser, buses, boats, marine, trailers,kitchen appliance etc.
  • 【DIY As You Like】Black Boat Rocker Switch, 3 terminals ON/OFF/ON switch, , longer life for use.
  • 【Product Basic Parameters】AC 20A/125V 22A/250V Overall Size:32 x 14 x 35mm (L*W*H) Mounting Size:30 x 10mm (L*W)
  • 【Attention】Select the appropriate soldering iron to speed up the soldering. It is recommended to use 20W soldering iron to complete the soldering within 3 seconds. The flux must be in proper amount. When soldering, try to turn the switch pin down.
  • 【Parcel contains】5x Rocker Switch Easy to install and durable.With our strict quality control system, we test each item and ensure in good condition before we ship.
Specification

Specification

Inquiry submitted successfully
We will reply within 24 hours during work time. If you haven't received the reply by then, please check your spam. Thank you!
Payments will be processed via the website or Stripe payment link. Please note that domain contact emails other than @harfington.com should not be trusted.
Product Description:

Specification:



Product Name:Rocker Switch

Pole and Throw:SPDT

Terminal Quantity:3

Position:On-Off-On

Rated Voltage:AC 20A/125V 22A/250V(for resistive load only)

Overall Size:32 x 14 x 35mm (L*W*H)

Mounting Size:30 x 10mm (L*W)

Color:Black

Material:Plastic, Metal

Package Content:5Pcs x Rocker Switch



 AC 250V Current for different loads

Inductive Load: 7.7A

Lamp Load: 3.96A

Motor Load: 4.4A

Capacity Load: 3.96A



AC125V Current for different loads

Inductive Load: 7A

Lamp Load: 3.6A

Motor Load: 4A

Capacity Load: 3.6A



Very Important Notice: Ratings on the switch label are only for Purely Resistive AC load, for other types of loads please refer to the ratings above.DC load Current ratings are much lower than AC load,if you need to use this switch with more than 0.5A DC load, contact us for compatibility at first.

Warning: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
$8.56 Regular price
/
Wholesale Price
35%OFF
Order $5000+
  • 35%OFF
    Order $5000+
  • 25%OFF
    Order $2000+
  • 15%OFF
    Order $800+
  • 10%OFF
    Order $500+
  • 5%OFF
    Order $200+
  • In stock, ready to ship
Cart
Cart
Free Shipping over $30

Product Variants

Products Title ID Price Qty
Products Title ID Price Qty
Qty: {[total.qty]} Item(s)
Total Price: {[handleCurrency(total.price*100)]}
View more

Description

Description

Specification:



Product Name:Rocker Switch

Pole and Throw:SPDT

Terminal Quantity:3

Position:On-Off-On

Rated Voltage:AC 20A/125V 22A/250V(for resistive load only)

Overall Size:32 x 14 x 35mm (L*W*H)

Mounting Size:30 x 10mm (L*W)

Color:Black

Material:Plastic, Metal

Package Content:5Pcs x Rocker Switch



 AC 250V Current for different loads

Inductive Load: 7.7A

Lamp Load: 3.96A

Motor Load: 4.4A

Capacity Load: 3.96A



AC125V Current for different loads

Inductive Load: 7A

Lamp Load: 3.6A

Motor Load: 4A

Capacity Load: 3.6A



Very Important Notice: Ratings on the switch label are only for Purely Resistive AC load, for other types of loads please refer to the ratings above.DC load Current ratings are much lower than AC load,if you need to use this switch with more than 0.5A DC load, contact us for compatibility at first.

Warning: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
