Harfington Uxcell CBB60 Run Capacitor 50uF 450V AC 2 Wires 50/60Hz Cylinder 105x50mm with Terminal for Air Compressor Water Pump Motor

Uxcell CBB60 Run Capacitor 50uF 450V AC 2 Wires 50/60Hz Cylinder 105x50mm with Terminal for Air Compressor Water Pump Motor

ID:1002188
ID:1002188
Wholesale Price
35%OFF
Order $5000+
  • 35%OFF
    Order $5000+
  • 25%OFF
    Order $2000+
  • 15%OFF
    Order $800+
  • 10%OFF
    Order $500+
  • 5%OFF
    Order $200+
About this item
  • [Specification] - Rated Capacity: 50uF; Tolerance: ±5%; Rated Voltage: 450V AC; Body Size: 105x50mm / 4.1x2inch(L*D); Rated Frequency: 50/60Hz; Climatic Category: 40/70/21
  • [Characteristic] - This CBB60 run capacitor has characteristics of small volume, light weight, low loss, anti-overvoltage shock, excellent electrical performance and long service life
  • [Working Environment] - This CBB60 capacitor is applied to starting and working of a single-phase motor in a 50Hz/60Hz AC electric power system
  • [Application] - The start capacitor is widely used for air compressors, water pumps, pressure washers, air conditioners, washing machines, motors, generators, HVAC, fans, drills, splitters, saws, grinders, etc
  • [Note] - 1. Before purchasing this product, please refer to the electrical specification of the original capacitor to select the appropriate capacitor; 2. This capacitor has no positive and negative poles, it can be wired at will. If the capacitor of your motor and air compressor is burnt out or weak, you need to replace it with a new one
About this item
  • [Specification] - Rated Capacity: 50uF; Tolerance: ±5%; Rated Voltage: 450V AC; Body Size: 105x50mm / 4.1x2inch(L*D); Rated Frequency: 50/60Hz; Climatic Category: 40/70/21
  • [Characteristic] - This CBB60 run capacitor has characteristics of small volume, light weight, low loss, anti-overvoltage shock, excellent electrical performance and long service life
  • [Working Environment] - This CBB60 capacitor is applied to starting and working of a single-phase motor in a 50Hz/60Hz AC electric power system
  • [Application] - The start capacitor is widely used for air compressors, water pumps, pressure washers, air conditioners, washing machines, motors, generators, HVAC, fans, drills, splitters, saws, grinders, etc
  • [Note] - 1. Before purchasing this product, please refer to the electrical specification of the original capacitor to select the appropriate capacitor; 2. This capacitor has no positive and negative poles, it can be wired at will. If the capacitor of your motor and air compressor is burnt out or weak, you need to replace it with a new one
Specification

Specification

SKU
a21011300ux0141
Material
Polypropylene,ABS
Body Size(L*D)
105*50mm
Frequency
50/60Hz
Terminal
2 Wires
Climatic Category
40/70/21
Capacitance
50µF
Brand
Uxcell
Pkg.Qty
1
Tolerance
±5%
Voltage
AC 450V
Inquiry submitted successfully
We will reply within 24 hours during work time. If you haven't received the reply by then, please check your spam. Thank you!
Payments will be processed via the website or Stripe payment link. Please note that domain contact emails other than @harfington.com should not be trusted.
Product Description:
Features:
This CBB60 run capacitor has characteristics of small volume, light weight, low loss, anti-overvoltage shock, excellent electrical performance and long service life.
The CBB60 capacitor is widely used for air compressors, water pumps, pressure washers, air conditioners, washing machines, motors, generators, HVAC, fans, drills, splitters, saws, grinders, etc.

Note:
This capacitor has no positive and negative poles, it can be wired at will.
If the capacitor of your motor and air compressor is burnt out or weak, you need to replace it with a new one.

Specifications:
Model: CBB60
Material: Polypropylene Film
Lead End: 2 Wires with Fork Terminal
Tolerance: ±5%
Rated Capacity: 50uF
Rated Voltage: 450V AC
Rated Frequency: 50/60Hz
Climatic Category: 40/70/21
Wire Length: 180mm / 7.1 inch
Body Size: 105x50mm / 4.1x2 inch (L*D)
Wire Color: Brown, Blue

Package Includes:
1 x CBB60 Capacitor
US$16.92 US$16.92/eachRegular price
US/
Wholesale Price
35%OFF
Order $5000+
  • 35%OFF
    Order $5000+
  • 25%OFF
    Order $2000+
  • 15%OFF
    Order $800+
  • 10%OFF
    Order $500+
  • 5%OFF
    Order $200+
  • Ship from the US
  • In stock, dispatch in 24 hours.
Cart
Cart
Free Shipping over US$30
30 Day Free Return

Product Variants

Products Voltage Capacitance Body Size(L*D) Terminal Tolerance Climatic Category Frequency Material Pkg.Qty ID Price Qty
AC 450V 50µF 105*50mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1002188 US$16.92
Products Voltage Capacitance Body Size(L*D) Terminal Tolerance Climatic Category Frequency Material Pkg.Qty ID Price Qty
AC 450V 50µF 105*50mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1002188 US$16.92
AC 450V 20µF 75*42mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1002404 US$9.92
AC 450V 4µF 54*34mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1001581 US$8.06
AC 450V 10µF 74*38mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1002353 US$12.39
AC 450V 100µF 120*60mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1002129 US$23.26
AC 450V 70µF 123*60mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1002093 US$19.65
AC 450V 35µF 96*50mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1002267 US$14.51
AC 450V 15µF 74*38mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1002383 US$9.24
AC 450V 16µF 74*38mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1002403 US$9.87
AC 450V 5µF 54*34mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1001915 US$8.36
AC 450V 80µF 123*60mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1001875 US$20.62
AC 450V 45µF 105*50mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1002504 US$14.91
AC 450V 60µF 123*50mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1001610 US$18.11
AC 450V 8µF 66*35mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1001862 US$8.57
AC 450V 40µF 96*50mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1002117 US$15.74
AC 450V 3µF 54*34mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1002356 US$7.85
AC 450V 22µF 72*42mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1002369 US$10.71
AC 450V 6µF 54*34mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1002346 US$7.97
AC 450V 30µF 96*50mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1002373 US$14.81
AC 450V 18µF 75*42mm 2 Wires ±5% 40/70/21 50/60Hz Polypropylene,ABS 1 1001790 US$9.95
AC 250V 6µF 54*34mm 2 Wires ±5% / 50/60Hz Polypropylene,ABS 1 1396337 US$7.14
AC 250V 50µF 105*50mm 2 Wires ±5% / 50/60Hz Polypropylene,ABS 1 1431820 US$12.88
AC 250V 25µF 75*40mm 2 Wires ±5% / 50/60Hz Polypropylene,ABS 1 1431821 US$9.63
AC 250V 12µF 73*38mm 2 Wires ±5% / 50/60Hz Polypropylene,ABS 1 1431824 US$8.68
AC 250V 40µF 96*50mm 2 Wires ±5% / 50/60Hz Polypropylene,ABS 1 1443455 US$11.65
AC 250V 10µF 73*38mm 2 Wires ±5% / 50/60Hz Polypropylene,ABS 1 1431783 US$8.84
AC 250V 120µF 96*49mm 2 Wires ±5% 40/85/21 50/60Hz Polypropylene,ABS 1 1095639 US$19.70
AC 250V 100µF 93*49mm 2 Wires ±5% 40/85/21 50/60Hz Polypropylene,ABS 1 1083447 US$20.49
Qty: 0 Item(s)
Total Price: US$0.00

Description

Description

Features:
This CBB60 run capacitor has characteristics of small volume, light weight, low loss, anti-overvoltage shock, excellent electrical performance and long service life.
The CBB60 capacitor is widely used for air compressors, water pumps, pressure washers, air conditioners, washing machines, motors, generators, HVAC, fans, drills, splitters, saws, grinders, etc.

Note:
This capacitor has no positive and negative poles, it can be wired at will.
If the capacitor of your motor and air compressor is burnt out or weak, you need to replace it with a new one.

Specifications:
Model: CBB60
Material: Polypropylene Film
Lead End: 2 Wires with Fork Terminal
Tolerance: ±5%
Rated Capacity: 50uF
Rated Voltage: 450V AC
Rated Frequency: 50/60Hz
Climatic Category: 40/70/21
Wire Length: 180mm / 7.1 inch
Body Size: 105x50mm / 4.1x2 inch (L*D)
Wire Color: Brown, Blue

Package Includes:
1 x CBB60 Capacitor
